Patent Pending Technology

The Future of Solar Roofing Is Here

Hybrid photovoltaic-thermal tiles that generate electricity, heat your water, and replace standard UK roof tiles with zero structural modification.

60-75% Combined Efficiency
8-15% More Power Output
35yr Extended Lifespan
Explore the Range Learn the Science
Low-iron tempered glass
Monocrystalline PV cells
Copper thermal conduit
Scroll to explore
The Innovation

Dual Energy
Harvesting

The world's first solar tile that generates electricity AND heats your water through a passive thermosiphon system requiring zero external power.

Photovoltaic Generation

Monocrystalline silicon cells with -0.30% to -0.40% per °C temperature coefficient, optimised for UK conditions.

Thermosiphon Cooling

Passive fluid circulation through natural convection—no pump required, no energy consumed, no mechanical failure points.

Temperature Optimisation

Cells maintained at 15-35°C optimal range, delivering 8-15% more electricity than uncooled alternatives.

Standard UK Dimensions

Direct replacement for cement tiles conforming to BS EN 490/491. No roof structure modification required.

Temperature vs Efficiency

15-35°C OPTIMAL 0% to -5%
35-45°C ACCEPTABLE -5% to -10%
45-65°C DEGRADED -10% to -20%
>65°C CRITICAL >-20%

Hobson Tiles actively regulate cell temperature to maintain peak efficiency

The Collection

Complete Tile
Range

Three formats matching the UK's most popular roof tile profiles. Direct replacements for industry-standard Marley tiles.

Close-up texture of flat grey interlocking roof tiles
Hobson Interlock — Flat interlocking profile
In Development

Hobson Interlock

Coming soon

Replaces: Marley Modern Interlocking

Our flagship tile featuring a flat profile with slate-like appearance. The most versatile option for modern and traditional UK homes.

420 × 330 × 25 Dimensions (mm)
9.7-10.7 Tiles per m²
~180W Output per m²
Request Specification
Close-up texture of double roman roof tiles
Hobson Roman — Mediterranean rolled edge profile

Hobson Roman

Coming soon

Replaces: Marley Ludlow Major

Mediterranean-inspired profile with distinctive rolled edges for character properties.

420 × 332 × 45 Dimensions (mm)
9.7 Tiles per m²
Close-up texture of S-curve pantile roof tiles
Hobson Pantile — Classic S-curve profile

Hobson Pantile

Coming soon

Replaces: Marley Lincoln

Classic S-curve pantile profile, ideal for coastal and period properties.

420 × 332 × 70 Dimensions (mm)
9.7 Tiles per m²

UK Standard Tile Compatibility

Hobson Tiles are designed as direct replacements for the UK's most popular Marley cement roof tiles

Marley Modern
Interlocking
Hobson Interlock
420 × 330mm
The Advantages

Why Choose
Hobson Tiles?

01

Zero Structural Changes

Direct replacement for standard UK cement tiles. Your existing roof structure remains untouched.

02

Passive Operation

The thermosiphon requires no pump, saving 50-100W versus active systems. Nothing to fail, nothing to maintain.

03

Dual Energy Harvest

60-75% combined efficiency versus 15-22% for PV-only. Generate electricity AND heat your water.

04

Optimised Efficiency

Active cooling keeps cells in the 15-35°C sweet spot, delivering 8-15% more electricity than standard panels.

05

Extended Lifespan

Lower operating temperatures reduce thermal degradation. Expect 30-35 years versus 25-30 for conventional systems.

06

Significant Savings

40-70% reduction in summer water heating costs. 10-30% annual reduction overall.

07

Standard Installation

Any qualified roofer can install. No specialist solar training or equipment required.

08

UK Climate Optimised

Cell selection and cooling parameters specifically tuned for temperate maritime conditions.

The System

How It
Works

A complete passive solar system that generates electricity, heats water, and regulates itself—all without pumps, controllers, or external power.

Thermal Storage Hot (35-50°C) Cool (15-25°C) ΔH ≥ 1.5m ⚡ To Grid/Battery
1

Solar Absorption

Sunlight passes through low-iron tempered glass to monocrystalline PV cells, generating electricity and heat.

2

Heat Transfer

Copper thermal interface conducts heat from cells to serpentine tubing, warming the circulating fluid.

3

Natural Circulation

Heated water rises to loft-mounted storage tank. Cooler water descends to replace it. No pump needed.

4

Dual Output

Electricity flows to your home or grid. Pre-heated water reduces your boiler's workload by up to 70%.

Installation Configurations

Series Connection

Maximum temperature rise (ΔT = 15-20°C). Ideal for hot water priority.

Parallel Connection

Uniform efficiency across all tiles. Best for electricity priority.

Recommended

Hybrid Series-Parallel

Balanced performance. Moderate temperature rise with consistent efficiency.

Rapid Installation

Quick-Connect
Coupling System

Tool-free push-fit connections enable installation in under 3 seconds per tile. Glass-reinforced polymer housings with stainless steel collet rings ensure leak-free operation at up to 90°C and 10 bar pressure.

  • 500+ connect/disconnect cycles
  • EPDM O-ring seals rated to 90°C
  • 8mm nominal bore for unimpeded flow
  • No specialist tools required
Get Started

Request a
Consultation

Interested in transforming your roof into a dual-energy power station? Get in touch for a free consultation and quote.
